The DX380LC-7K model features a new generation engine to meet the latest Stage V engine emission regulations.
It is a new solution without exhaust gas recirculation (EGR) to increase the quantity of air during combustion - the temperature during combustion is therefore higher and the amount of emission particles are reduced as much as possible. Thanks to the new technology, the diesel particle filter (DPF) requires really low maintenance.
Download Brochure Find a Dealer

Machine Specs

Operating weight 40.200 kg
Engine Scania DC09
Engine power 240 kW (326 HP) @ 1800 rpm (SAE J1995)
Main pumps max flow 2 x 350 l/m
Number of cylinders 5
Travel speed 3.0 / 5.4 km/h
Maximum traction 43.4 t
Buckets 1.25 – 2.32 m³
Tail swing radius 3530 mm
Bucket digging force 25.9 t
Arm digging force 23.3 t
Max. digging reach 11930 mm
Max. digging depth 8165 mm
Max. digging height 10940 mm

Options & Attachments

Quick Coupler

Part name Part # Pin Diameter (mm) Min - Max Centers (x - y )mm) Base Width  (mm) Weight  (kg (lbs))
24 - 35t Quick Coupler QC90 (H) (M) 90 380 - 570 320 930 (422)
