DX57W-7

Operating weight

5.800 kg

Bucket capacity

0.175 m3

Engine

42.5 kW / 2.400 RPM

DX57W-7

Boost your productivity

The DX57W-7 takes even the heaviest tasks in its stride with efficient, dependable performance that saves you time and money.


The DX57W-7 is equipped with a Develon D24 Stage V engine. Famous for excellent fuel efficiency, reliability and long service life, it combines exceptional power output and high torque at low revs. Diesel Oxidation Catalyst (DOC) and Diesel Particulate Filter (DPF) ensure compliance with Stage V regulations.

Specifications

Machine Specs

Operating weight 5.800 kg
Bucket capacity 0.175 m3
Engine 42.5 kW / 2.400 RPM
Model Develon D24 (SAE J1349)
Width 2290 mm



Max. reach ground level (short / long arm) 5880 / 6190 mm
Max. digging depth (std / long arm) 3495 / 3795 mm
Max. digging force - bucket 4.2 t
Max. digging force - arm (short / long arm) 2.8 / 2.5 t
Travel speed 0 / 30 km/h

DX57W-7

Options & Attachments

Quick Coupler

Part Name Part # Pin Diameter (mm) Min - Max Centers (x - y )mm) Base Width  (mm) Weight  (kg (lbs))
5-7t Quick Coupler QC45 (H) (M) 45 218 - 394 144/150 139 (63)

Bucket

Part Name Part # Width (mm) Capacity (m3) Weight (kg)
Bucket H06-0450 H06-0450 450 0,097 95
Bucket H06-0750 H06-0750 750 0,182 139
Bucket H06-0900 H06-0900 900 0,224 152
Bucket G06-1500 G06-1500 1500 0,236 170
