DX210NLC-7

Maximum power

166 hp

Operating weight

22.100 kg

Bucket capacity

0.92 m3

DX210NLC-7

Boost your productivity

Lift your business to the next level with the DX210-7/LC-7/NLC-7 Develon excavators. Exceptionally powerful, yet environmentally friendly, the DX210-7/LC-7/NLC-7 excavators feature extraordinary fuel efficiency.

3 DIFFERENT UNDERCARRIAGES POSSIBLE, TO PERFECTLY MATCH YOUR APPLICATION.

DX210-7 – for the best balance between transportability and low ground pressure: Standard undercarriage, 2800 mm width with 600 mm shoes / 2900 mm with 700 mm shoes / 3000 mm with 800 mm shoes.

Dx210LC-7 – for the best stability: Long and wide undercarriage, 2990 mm width with 600 mm shoes.

DX210NLC-7 – to meet Italian regulations: Long and narrow undercarriage, 2540 mm width with 500 mm shoes.


Specifications

Machine Specs

Maximum power 166 hp
Operating weight 22.100 kg
Bucket capacity 0.92 m3
Emission standard Stage V
Engine Develon DL06V
Number of cylinders 6
Engine power 124 kW / 166 HP @ 1800 RPM



Arm lenght 2400 – 2600 mm
Boom lenght 5600 – 5850 mm
BUCKET (Normal/Press. Up) 15.6 - 16.5 t
ARM (Normal/Press. Up) 10.8 - 11.4 t
Main pumps max flow 2 × 210.6 l/min
Buckets 0.51 - 1.32 m3
