DX420LC-7K

Operating weight

43.500 kg

Buckets

1,5 – 2,1 m³

Engine

Scania DC13

DX420LC-7K

Enjoy Unparalleled Efficiency

Lift your business to the next level with the new DX420LC-7K Develon excavators!

More infromation

Exceptionally powerful, yet environmentally friendly, the  DX420LC-7K excavator equipped
with the latest generation Scania DC13 engine features extraordinary fuel efficiency.

Specifications

Machine Specs

Operating weight 43.500 kg
Buckets 1,5 – 2,1 m³
Engine Scania DC13
Maximum power 344 HP
Emission standard Stage V
Engine power 257 kW (344 HP) @ 1800 rpm (SAE J1995)
Main pumps max flow 2 x 333 l/m
Number of cylinders 6
Travel speed 3.2 / 5.3 km/h



Maximum traction 43.4 t
Bucket capacity 2.2 m³
Tail swing radius 3760 mm
Max. digging reach 12120 mm
Max. digging depth 8335 mm
Max. loading height 8200 mm
Max. digging height 11045 mm
BUCKET (Normal/Press. Up) 26.5 / 28.1 t
ARM (Normal/Press. Up) 23.5 / 24.9 t
