DX490LC-7K

Operating weight

50.400 kg

Buckets

1.71 – 3.6 m³

Engine

Scania DC13

DX490LC-7K

Boost your productivity

Lift your business to the next level with the new DX490LC-7K Develon excavatos!

Exceptionally powerful, yet environmentally friendly, the  DX490LC-7K excavators equipped with the latest generation Scania DC13 engine features extraordinary fuel efficiency.

Specifications

Machine Specs

Operating weight 50.400 kg
Buckets 1.71 – 3.6 m³
Engine Scania DC13
Maximum power 394 HP
Emission standard Stage V
Engine power 294 kW (394 HP) @ 1800 rpm (SAE J1995)
Main pumps max flow 2 x 390 l/m
Number of cylinders 6
Travel speed 3.2 / 5.6 km/h



Maximum traction 45.7 t
Bucket capacity 3.0 m³
Tail swing radius 3800 mm
Max. digging reach 11720 mm
Max. digging depth 7340 mm
Max. loading height 7725 mm
Max. digging height 10920 mm
BUCKET (Normal/Press. Up) 29.0 / 30.8 t
ARM (Normal/Press. Up) 24.4 / 25.8 t

DX490LC-7K

Options & Attachments

Quick Coupler

Part name Part # Pin Diameter (mm) Min - Max Centers (x - y )mm) Base Width  (mm) Weight  (kg (lbs))
50 - 65t Quick Coupler QC120 (H) 120 570 - 635 428/468 2402 (1090)
