DX235LC-7

Maximum power

173 hp

Operating weight

23.300 kg

Bucket capacity

1.3 m3

DX235LC-7

Boost your productivity

Lift your business to the next level with the next generation DX235LC-7 Develon excavator. Exceptionally powerful, yet environmentally-friendly, the DX235LC-7 excavator is designed for the toughest applications.

The DX235LC-7 is equipped with the latest generation Develon engine. Stage V compliant, this engine boasts extremely low emissions because reducing our environmental impact is paramount to us. Exhaust gases are purified by Selective Catalytic Reduction (SCR) technology, a Diesel Oxidation Catalyst (DOC) and a Diesel Particulate Filter (DPF).


Specifications

Machine Specs

Maximum power 173 hp
Operating weight 23.300 kg
Bucket capacity 1.3 m3
Emission standard Stage V
Engine Develon DL06V
Number of cylinders 6
Engine power 129 kW / 173 hp @ 1800 rpm



Bucket capacity 0.81 – 1.05 m³
Arm lenght 2400 – 2800 mm
Boom lenght 5700 – 5850 mm
BUCKET (Normal/Press. Up) 15.6 - 16.5 t
ARM (Normal/Press. Up) 10.9 - 13.4 t
Main pumps max flow 2 × 210.6 l/min

DX235LC-7

Options & Attachments

Quick Coupler

Part name Part # Pin Diameter (mm) Min - Max Centers (x - y )mm) Base Width  (mm) Weight  (kg (lbs))
16 - 29t Quick Coupler QC80 (H) (M) 80 385 - 530 280/300 628 (285)

Bucket

Part name Part # Width (mm) Capacity (m3) Weight (kg)
Bucket H25-1500 H25-1500 1500 1,09 1031
